ESS-BATT RE Series – High-Voltage Industrial Energy Storage (48–107 kWh)
The ESS-BATT RE Series delivers scalable high-voltage energy storage for commercial and industrial applications, offering flexible capacity from 48 kWh to 107 kWh and voltages between 384 V and 844.8 V. Engineered for reliable solar integration, peak shaving, backup power, and microgrid support, this LiFePO₄ battery system ensures efficient, cost-effective, and uninterrupted energy while enhancing long-term operational resilience for businesses.
ESS-BATT RE Series High-Voltage Industrial Energy Storage
The ESS-BATT RE Series delivers scalable high-voltage LiFePO4 energy storage for commercial and industrial applications. With flexible capacity ranging from 48 kWh to 107 kWh and operating voltages between 384 V and 844.8 V, this system is engineered for solar integration, peak shaving, backup power, and microgrid support. It ensures efficient, cost-effective, and uninterrupted energy while enhancing long-term operational resilience for businesses.
Empower Industrial Operations with ESS-BATT RE
The ESS-BATT RE Series from BSLBATT offers modular high-voltage energy storage with models RE5, RE7, RE9, and RE11, covering voltage levels from 384 V to 844.8 V. Built with advanced LiFePO4 cells and a smart BMS, it delivers high safety, long cycle life, and flexible scalability for demanding industrial and commercial energy storage environments.
Key Features – ESS-BATT RE Series
- Modular 9.75 kWh battery packs scalable from 48.8 kWh to 107.3 kWh
- Parallel expansion up to megawatt-scale capacity
- Long service life with >4,000 cycles @80% DOD (25℃)
- 1C fast charge and discharge capability
- Advanced BMS with over-voltage, over-temperature, and short-circuit protection
- High energy density design saving up to 30% installation space
- Wide operating temperature range: -20℃ to 55℃
- Operating humidity range: 15%–90% RH (non-condensing)
- Supports CAN and ModBus communication protocols
- Ideal for solar integration, backup power, peak shaving, and microgrids
Compact & Efficient Indoor Installation
Designed for indoor industrial environments, the ESS-BATT RE Series features a compact footprint, high system efficiency, and optional fire protection, ensuring safe and reliable operation in demanding conditions.
System Configuration Options
- RE5 – 384 V system configuration
- RE7 – Mid-range high-voltage configuration
- RE9 – Extended capacity configuration
- RE11 – Up to 844.8 V high-voltage configuration
Technical Specifications – ESS-BATT RE Series
- Cell Capacity: 3.2 V / 127 Ah
- Cell Chemistry: Lithium Iron Phosphate (LiFePO4)
- Rated Voltage (Single Pack): 76.8 V
- Rated Energy (Single Pack): 9.753 kWh
- Weight (Single Pack): 70 kg ±3%
- Dimensions (H × W × D): 135 × 740 × 645 mm
- Number of Packs: 5
- System Rated Voltage: 384 V
- Operating Voltage Range: 336 V – 432 V
- Recommended Voltage Range: 348 V – 420 V
- Rated Charge / Discharge Current: 42.4 A
- System Rated Energy: 48.768 kWh
- Cycle Life: >4,000 fast charge cycles @80% DOD (25℃)
- Operating Temperature: -20℃ ~ 55℃
- Operating Humidity: 15% – 90% RH (Non-condensing)
- Installation Environment: Indoor
- Fire Protection (Pack): Optional
- Communication Protocol: CAN / ModBus
- Ingress Protection: IP20
- Dimensions (L × W × H): 1140 × 764 × 740 mm
- Weight (Total Cluster): 420 kg ±3%
