16kWh 51.2V 314Ah LiFePO₄ House Battery | Li-Pro StyX Solar Wall Battery
The BSLBATT 16kWh 51.2V 314Ah lithium ion house battery is a high-performance LiFePO₄ solar energy storage system designed for residential and commercial applications. Engineered with Tier One A+ LiFePO₄ cells, it delivers exceptional efficiency, long cycle life, and superior safety. Perfect for solar systems and backup power, the Li-Pro StyX ensures stable, eco-friendly energy for modern homes and businesses.
Key Features – Li-Pro StyX 16kWh Battery
- Supports up to 15 units in parallel, expandable to 240kWh total capacity
- Compact wall-mounted or floor-standing design with IP54 protection
- Natural air cooling for reliable indoor or outdoor operation
- 90% Depth of Discharge (DOD) with over 8000 cycles lifespan
- Seamless integration with most hybrid inverters
- Multiple communication options: RS232, RS485, CAN, WiFi, Bluetooth
- 10-year warranty with intelligent battery management system
- Non-toxic, cobalt-free LiFePO₄ chemistry for safety
- Built-in aerosol fire extinguisher for additional protection
- Parallel connection of up to 32 units with modular stacking capability
- Maximum continuous 1C discharge for reliable power delivery
- Remote APP monitoring and OTA updates (WiFi/Bluetooth optional)
Benefits
Maintain uninterrupted power and enjoy lower electricity bills. The 16kWh storage capacity meets all daily electricity needs, maximizes solar self-consumption, and supports an eco-friendly lifestyle. Simple design and easy installation make the Li-Pro StyX an essential energy guardian for every home.
Technical Specifications – Li-Pro StyX 16kWh
- Model: Li-PRO 15360
- Battery Type: LiFePO₄
- Nominal Voltage: 51.2V
- Nominal Capacity: 15360Wh
- Usable Capacity: 13824Wh
- Cell Configuration: 16S1P
- Dimensions (W×H×D): 750×830×220mm
- Weight: 132kg
- Discharge Voltage: 47V
- Charge Voltage: 55V
- Charge Rate / Power: 150A / 7.68kW
- Max Charge Current / Power: 240A / 12.288kW
- Peak Charge Current / Power: 310A / 15.872kW
- Discharge Rate / Power: 300A / 15.36kW
- Max Discharge Current / Power: 310A / 15.872kW, 1s
- Peak Discharge Current / Power: 400A / 20.48kW, 1s
- Communication: RS232, RS485, CAN, WiFi(optional), Bluetooth(optional)
- Depth of Discharge: 90%
- Expansion: Up to 32 units in parallel
- Operating Temperature: Charge 0~55℃, Discharge -20~55℃
- Storage Temperature: 0~33℃
- Short Circuit Current / Duration: 350A, 500μs
- Cooling Type: Natural
- Protection Level: IP65
- Monthly Self-Discharge: ≤3%
- Humidity: ≤60% RH
- Altitude: <4000m
- Warranty: 10 Years
- Design Life: >15 Years (25℃)
- Cycle Life: >6000 cycles @25℃
